AI Face Recognition Time Attendance Access Control Device

Product name

Al Dynamic Face Recognition Time Attendance Access Control Terminal

Screen

8.0 Inch. HD 800*1280, Capacitive Touch Screen

Keypad

Touch keypad

Operation system

LINUX 3.10

CPU.NPU

1.2G Dual-Core ARM Cortex-A7,1200G (1.2T)

RAM

512MB DDR3L

ROM

eMMC Flash8GB micro camera

Binocular camera

200W Colorful WDR+200W Infrared live camera

Logs capacity

500000

Face Registration

Local operation: Enroll face with machine, import user photo with U disk

Software operation: Import user photo to software, capture user photo with camera

Verification

Dynamic face recognition, password, ID/IC card optional

Face capacity

20000

Card Capacrty

20000. ID and IC Card

Password Capacity

20000

Face Recognition Accuracy

99.70%

Recognition Speed

s0.2s, support single user/multi user(at most 5 users) recognition at same time

Recognition Distance

0 5-2.5 meters (0.5*1.5 meters with live face recognition on)

Prevent Photo

Dual camera anli-counlerfeiting, prevent recognition with pholo/video

Principle of Identification

Face algorithm technology of multi-task cascaded convolutional neural network based on video stream for dynamic face detection,
tracking and recognition

WDR

Wide dynamic range, support accurate face recognition under Strong light, dark light and backlight

USB

USB2.0 x 1 f Support U disk import/export data

Power supply

DC 12V interface x 1

Speaker Interface

Reserved for extended Speaker Interface

Network Communication

TCP/IP Support C/S LAN communication. Wifi (optional)

Free Attendance software

Support exporting excel attendance report with U disk

Shift

Support shift setting and importing shift schedule with U disk

Management Software

Support PC software to manage data through network connection with equipment

Access Control Function

Door unclosed alarm, forced door opening alarm, alarm linkage and output, one set of door opening signals, one set of alarm
signals, time permission control, connect external access control reader, Wiegand 26/34 Output&lnput

Environmental adaptability

Working temperature: -15°C~+45°C (storage temperature -40°C~+65°C),

Working humidrty: 20%~90% (storage humidity 20%~90±2%).

Dark enviroment: LED Soft light automatic fill light (Automatic control according to ambient light)

Ambient light adaptation range: 0-50000Lux

Multi language

English. Spanish, Arabic, Thai. Farsi. Portuguese, French, Italian, Japanese, Korean, etc

Broadcase and ring

Support display name, voice broadcase name builtin bell ring

Automatic fill light

Support infrared fill light, the white fill light automatically lights up when face is captured in dark light

Working Current

stand-by current: 310mA , Working current: 520mA

QR Code Scanner

Support

Working Voltage

DC 12V

Installation Way

Standard: Wall mount, desktop stand; Optional: bracket for turnstile, floor stand

Machine Dimension

265x132 6x20mm

Carton dimension

Size: 480x438x229mm, 12Kg/cartonr 10units/carton
